Grade 14 Concealed Knuckle Hinge SS201 – Hospital Tip

Grade 14 Concealed Knuckle Hinge SS201 – Hospital Tip

The Grade 14 Concealed Knuckle Hinge SS201 – Hospital Tip is a heavy-duty architectural hinge designed for high-performance commercial and healthcare environments. Featuring a concealed knuckle design with a hospital tip profile, this hinge delivers enhanced hygiene, durability, and smooth door operation while maintaining a clean professional appearance.

Manufactured from durable Grade 201 stainless steel, this hinge is engineered for demanding applications and is capable of supporting doors weighing up to 160kg. Its self-lubricating mechanism ensures reliable long-term performance with minimal maintenance requirements, making it ideal for hospitals, public buildings, and high-traffic environments.

Key Features

• Heavy-duty concealed knuckle hinge design
• Hospital tip profile for improved hygiene and safety
• Manufactured from Grade 201 stainless steel
• Self-lubricating hinge mechanism
• Low maintenance operation
• Suitable for doors up to 160kg
• Durable and reliable for high-traffic environments
• Suitable for commercial and healthcare applications

Available Finish

• Satin Stainless

Specifications

• Product Type: Concealed Knuckle Hinge
• Hinge Size: 102 x 76 x 3mm
• Material: Grade 201 Stainless Steel
• Tip Style: Hospital Tip
• Maximum Door Weight: 160kg
• Operation: Self-Lubricating
• Maintenance: Low Maintenance Design
• Compliance Standard: BS EN 1935:2002
• Grade: Grade 14
• Certifications: CE 2812, Certifire, UKCA 1121

Suitable Applications

• Hospitals and healthcare facilities
• Commercial buildings
• Public access buildings
• Educational facilities
• Heavy-duty internal doors
• High-traffic environments
