Step-by-Step Guide: Replacing a Euro Cylinder Lock

March 21, 2025

A Euro cylinder lock is one of the most common types of locks found on uPVC and composite doors. Whether you’ve lost your keys, experienced a break-in attempt, or simply want to upgrade your home security, replacing a Euro cylinder lock is a simple DIY task that doesn’t require advanced skills.

By following a few straightforward steps, you can remove the old cylinder, fit a new one, and ensure it works smoothly—all without needing a locksmith. However, selecting the right-sized lock is required for proper security and functionality.

This guide on how to replace a Euro cylinder lock will walk you through the process, covering everything from the tools required to troubleshooting potential issues. By the end, you’ll have a secure and fully operational new lock in place.

Step 1: Gather the Necessary Tools and Materials

Before starting, make sure you have everything you need. Having the right tools on hand will make the process smoother and help avoid unnecessary delays.

Essential tools and materials:

✔ Screwdriver (Phillips or flathead, depending on your door) – Used to remove the fixing screw.
✔ Measuring tape – Needed to measure the existing lock for a correct replacement.
✔ Replacement Euro cylinder lock – Ensure it’s the right size and security rating.
✔ Key – Required to remove the old lock and test the new one.

Safety tips:

Wear gloves to protect your hands from sharp edges.
Work in a well-lit area for better visibility.

When buying a replacement lock, consider anti-snap or high-security models for added protection. Many hardware stores and online retailers offer a range of Euro cylinders to suit different security needs.

Step 2: Remove the Old Euro Cylinder Lock

With your tools ready, it’s time to remove the existing lock. Follow these steps carefully to avoid damaging the door or lock mechanism.

Locate the fixing screw – Open the door and find the long screw on the edge of the door, near the middle of the lock. Use a screwdriver to fully unscrew and remove it. Keep the screw safe, as you’ll need it for the new lock.
Insert the key and align the cam – Place the key into the lock and turn it slightly (about 10–15 degrees) to align the cam (the central locking mechanism) with the body of the lock. This is necessary to slide the cylinder out.
Remove the cylinder – While keeping the key in position, gently pull the cylinder out of the door. If it feels stuck, wiggle the key slightly while applying light pressure.

Troubleshooting tip:

If the lock won’t budge, check that the fixing screw is fully removed. A small spray of lubricant can also help loosen a stiff cylinder.

Step 3: Measure and Select the New Cylinder

To ensure a secure fit, you need to measure the old cylinder before buying a replacement. An incorrectly sized lock may not function properly or could leave your door vulnerable to forced entry.

Measure the existing lock – Use a measuring tape to determine the length from the centre fixing hole to each end of the cylinder. You’ll get two measurements (e.g., 40mm internal / 50mm external). These must match your new cylinder.
Check the lock type – Euro cylinders come in different styles:

Standard – Basic security, but vulnerable to snapping.
Anti-snap – Designed to resist forced entry methods.
Thumb-turn – Allows keyless locking from the inside.

Choose a secure option – Opt for a cylinder with a British Standard (BS EN 1303) or TS007 3-star rating for better security.

When purchasing, ensure the new cylinder matches your door’s thickness and locking mechanism. Many hardware stores provide size guides to help with selection.

Step 4: Install the New Euro Cylinder

With the correct replacement cylinder ready, it’s time to install it. Follow these steps to ensure a smooth and secure fit.

Insert the new cylinder – Place the key into the lock and align the cam so it slides into the door easily. Make sure it sits flush with the door’s surface.
Secure with the fixing screw – Reinsert the long fixing screw into the hole on the door’s edge. Tighten it with a screwdriver, but avoid overtightening, as this could affect the lock’s function.
Test the key operation – Turn the key in both directions to check that the lock engages smoothly. The key should rotate without resistance and fully lock/unlock the door.

Troubleshooting tips:

If the cylinder won’t fit, double-check the size.
If the key is stiff, loosen the fixing screw slightly and test again.

Once the lock works correctly, your new Euro cylinder is securely in place.

Step 5: Test the Lock for Proper Functionality

Before considering the job complete, test the new lock to ensure it operates correctly and provides proper security.

Check the key operation – Insert the key and turn it both ways to confirm the lock engages smoothly. If the key sticks or feels stiff, loosen the fixing screw slightly and try again.
Test from both sides – If it’s a double-cylinder lock, check that both keys work correctly. If using a thumb-turn lock, ensure it locks securely from the inside.
Ensure the door closes properly – Shut the door and lock it. The mechanism should engage without resistance, and the door should sit flush within the frame.

For added security, consider upgrading to an anti-snap lock if you haven’t already. A well-fitted lock enhances home security and ensures peace of mind.

Replacing a Euro cylinder lock is a quick and cost-effective way to improve your home’s security. With the right tools and a step-by-step approach, you can swap out your old lock in minutes, ensuring your door is safe and functional.

If you're upgrading for better protection, consider high-security options like anti-snap or TS007-rated cylinders. Need expert advice or quality locks? Love Handles has a range of secure and stylish door hardware to suit your needs.

Explore our collection today and take the next step towards a safer home.
